Material: stainless steel wire
Inner tube: EPDM
Special designs are available
Size: 15mm x 1/2-inch x 300mm
Taizhou Gaosibei metal Hose Co., Ltd. was estiblished in 2005, with brand Gaosibei registered in 2009 formally. The company is situated in Wenling, which sharing the first ray of sunshine in the new century of China.
Gaosibei Company is mainly engaged in production of standard, single-lock, double-lock and the explosion-proof flexible hoses and protective tubes which are widely used in the fields of wires & cables, equipment manufacturing, buildings, ships, rails, civil aviation and public facilities, etc.
Gaosibei Company insists on modern scientific management, set up a complete marketing network based on product quality, and keeps innovating in science and technology. Gaosibei supplies not only reliable products and reasonable price, but also sincere and satisfaction service.
Looking forward, Gaosibei Company will insist on the Honest & Innovative business philosophy and keep pursuiting better and higher quality of our products to make Gaosibei hose the first choice of all users.
|
Item No. |
Specifications |
Outer diameter and tolerance (mm) |
Natural curve (mm) |
Max. axial pull (Kg) |
Packaging unit ( M ) |
|
Metric |
G system |
|
GSB-JSB-MT-6 |
¦µ 6 |
3/16 |
9.00¡À 0.25 |
40 |
335 |
100 |
|
GSB-JSB- MT-8 |
¦µ 8 |
5/16 |
11.8¡À 0.30 |
45 |
470 |
100 |
|
GSB-JSB- MT-10 |
¦µ 10 |
1/4 |
14.5¡À 0.30 |
55 |
590 |
100 |
|
GSB-JSB- MT-12 |
¦µ 12 |
- |
16.5¡À 0.35 |
60 |
710 |
100 |
|
GSB-JSB- MT-13 |
¦µ 13 |
3/8 |
17.5¡À 0.35 |
65 |
765 |
100 |
|
GSB-JSB- MT-15 |
¦µ 15 |
- |
20.2¡À 0.35 |
80 |
885 |
50 |
|
GSB-JSB- MT-16 |
¦µ 16 |
1/2 |
21.2¡À 0.35 |
85 |
940 |
50 |
|
GSB-JSB- MT-19 |
¦µ 19 |
- |
24.5¡À 0.40 |
95 |
1120 |
50 |
|
GSB-JSB- MT-20 |
¦µ 20 |
3/4 |
25.5¡À 0.40 |
100 |
1180 |
50 |
|
GSB-JSB- MT-25 |
¦µ 25 |
1 |
31.7¡À 0.45 |
120 |
1450 |
25 |
|
GSB-JSB- MT-32 |
¦µ 32 |
1 1/4 |
39.6¡À 0.50 |
150 |
1885 |
25 |
|
GSB-JSB- MT-38 |
¦µ 38 |
1 1/2 |
46.6¡À 0.60 |
180 |
2240 |
20 |
|
GSB-JSB- MT-51 |
¦µ 51 |
2 |
59.5¡À 1.00 |
220 |
3000 |
10 |
|
GSB-JSB- MT-64 |
¦µ 64 |
2 1/2 |
73.5¡À 1.50 |
310 |
3770 |
10 |
|
GSB-JSB- MT-75 |
¦µ 75 |
3 |
83.5¡À 2.00 |
350 |
4405 |
10 |
|
GSB-JSB- MT-100 |
¦µ 100 |
4 |
108.5¡À 3.00 |
410 |
4700 |
10 |
Your positon: Home > sell Corrugated hose, metal hose
sell Corrugated hose, metal hose25
Product Description£º
